Product Features
- Compact UV system suitable for small to medium flow and head-loss capacities
- Flexible modular design for new plant installations or retrofit of shallower channels such as horizontal UV channels
- 600 Watt EcoRay® UV lamps and ballasts using Xylem technology
- Automatic, low maintenance non-chemical self-cleaning system
- Automatic and manual module lifting options eliminate the need for costly cranes, and ergonomical design ensures easy operation
- Maintenance-free electric drives that require no hydraulic oils or expensive upkeep
The vertically inclined WEDECO brand Duron® 6 UV system has over 10 years installation and field experience. This flexible, automatically controlled open channel UV system is specifically developed for wastewater and is ideal for secondary and tertiary effluent.
Efficient, reliable UV treatment solution lowers your energy consumption
Features OptiDose™ control, that automatically adjusts energy consumption and power to the UV lamps to the minimum number required to meet dosing requirements, saving energy costs and operational costs.
Outstanding flexibility to upgrade and retrofit with lower capital costs
Easy to convert and upgrade your vertical or horizontal UV system with minimal channel adjustment and lower construction costs. A range of upgrade choices and flexibility in bank width and channel length enables designs that easily adapt to accommodate changing flows or to conform to new regulations.
Safe and easy maintenance
Optional manual or automatic lifting mechanism allows for safer access to modules without the need for a crane. Individual modules can be lifted while other banks of modules remain in service, ensuring high up-time. All electrical components are housed out of the water in separate cabinets for additional safety.
Validated disinfection capabilities
WEDECO brand Duron® 6 UV disinfection systems have undergone third-party validation testing in accordance with the UVDGM (USEPA, 2006) and the US National Water Research Institute (NWRI). Validated products are tested to confirm a minimum inactivation equivalent of 3 log (99.9%) for target microorganisms in accordance with NWRI and UVDGM. Performance is not claimed nor implied for any product not yet validated; unvalidated products use single point summation calculations to provide delivered dose recommendations. Performance limitations depend on feed conditions, overall installed system design, and operation and maintenance processes; please refer to Operations Manuals.
