HVAC & Refrigeration
AlfaNova
Manufactured with Alfa Laval’s patented AlfaFusion technology, AlfaNova is a heat exchanger consisting of corrugated stainless steel plates bonded together without any copper or nickel. The unique design means that AlfaNova can withstand more extreme temperatures and pressures with greater fatigue resistance than conventional brazed plate heat exchangers. It is also suitable for duties with very high hygiene demands.
Compound Screw Compressor
The compound C-series is the power of one designed for the duty of two. By combining the high and low stage rotors in one body it permits a 2 stage operation in one compressor. With two compressors in one you minimize your initial costs, footprint and maximize your output. Applications are found in many areas through two stage systems, low temperature fields and sites with high compression ratios.
EJETHE
Medium to large size unit coolers for freezers, coolers and docks requiring medium and low temperature applications. The EJETHE series offers the heat transfer technology of the SSTME with the product features of the SSTLE including the improved accessibility features, clean cabinet/pan design and corrosion inhibiting materials of construction.
Constructed with heavy wall, 5/8 inch OD, Stainless Steel tubing featuring CrossCool™ Internal Tube Enhancement
Standard Aluminum Fin construction featuring ChannelFlow™ Fin Technology as standard (available with 3.3, 4.3, and 6 fins per inch)
Ejector recirculated direct expansion for ammonia applications.
Heavy-duty sheet metal fans, with cast aluminum fan blades available for low-temperature applications
Low sound fan motors ranging from 1-1/2 horsepower to 7-1/2 horsepower in 870, 1160, and 1750 RPM
G-235 hot dip galvanized steel casing and dual-sloped drain pan
Hygienic cabinet design
Easy installation
AHRI Standard 420 Certified™
15-38% Capacity Increase Over Traditional DX! Nearing Recirculated Capacities!
5/8” Diameter Tube, Vertical Coil Designs (except SSTD)
Ammonia Applications
“Ejector Recirculated” for Stable System Operation
AHRI Certified Ratings
Patented Technology
EJETME
Small to medium size unit coolers for freezers, coolers and docks requiring low, medium and high temperature applications. EJETME Series evaporators offer improved accessibility features, clean cabinet/pan design and corrosion inhibiting materials of construction. EJETME evaporators are offered with Stainless Steel tube/Aluminum fin with a hygienic cabinet design.
EJETME units are constructed with heavy wall, 5/8 inch OD, stainless steel tubing featuring CrossCool™ Internal Tube Enhancement
Standard Aluminum Fin construction featuring ChannelFlow™ Fin Technology as standard (available with 3.3, and 4.3 fins per inch as standard)
Ejector recirculated direct expansion for ammonia applications.
Heavy-duty sheet metal fans, with cast aluminum fan blades available for low-temperature applications
Low sound fan motors ranging from ¼ horsepower to 5 horsepower in 690, 870, 1160, and 1750 RPM
G-235 hot dip galvanized steel casing and dual-sloped drain pan
Hygienic cabinet design
Easy Installation
AHRI Standard 420 Certified™
15-38% Capacity Increase Over Traditional DX! Nearing Recirculated Capacities!
5/8” Diameter Tube, Vertical Coil Designs (except SSTD)
Ammonia Applications
“Ejector Recirculated” for Stable System Operation
AHRI Certified Ratings
Patented Technology
